T-18QG Hotplate (Digital, 180mm, handle), US plug, 120V, 60Hz
Manufacturer: Jeio Tech
Product Details
Performance & Convenience
- Microprocessor PID temperature control.
- Auto-tuning and temperature calibration functions.
- Multi-functional temperature control modes. (optimal / fast / slow / user / point)
- Optimum heating level is adjustable from 0 to 100%.
- Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.
- Precise temperature is set by digital display and optimum heating level is adjustable.
- Advanced dual wait on/off timer modes.
- User can set timer to starts immediately after the timer setting or only after reaching the set temp. - Separate operation RUN/STOP button.
- Non-slip heating bath with concavo-convex bottom prevents unintentional slips of the bath. (optional)
- A transparent safety shield protects users from liquid splashes. (optional)
- Support rod allows for diverse flexibility in configuring other test equipment and accessories. (optional)
Safety
- Built in thermal shut off and current limit protection.
- High and low temperature limit setting for user convenience and safety.
- Hot top warning indicator for preventing accidental injuries.
- Keypad lock function prevents accidental changes during operation.
| Model | T-14SG | T-17SG | T-18QG | |
|---|---|---|---|---|
| Heating | Temperature range (? / ?) | Max. 350 / 662 | ||
| Control | Feedback control with PID | |||
| Display | LED digital (0.1? resolution) | |||
| Heating power (W) | 600 | 800 | ||
| Safety | Hot top indicator (? / ?) | Warning lamp (50 / 122) | ||
| Over temp. | Top plate / Main body / PCB | |||
| Over current | Current limit protection | |||
| Timer | 2 type, 1min. to 99 hr. 59 min. | |||
| Load, Max. (kg / Ibs) | 25 / 55.1 | |||
| Top plate | Shape | Round type | Square type | |
| Material | Ceramic coated aluminum | |||
| Dimension | 140 / 5.5 | 170 / 6.7 | 180x180/ 7.08x7.08 | |
| Body | Shape | Straight body | Straight body | Straight body |
| Material | Aluminum | |||
| Dimension | 161x290x100/ 6.34x11.42x3.94 | 191x330x101/ 7.52x12.99x3.98 | 209x326x102/ 8.22x12.83x4.0 | |
| Net weight (kg / Ibs) | 2.2 / 4.9 | 2.9 / 6.4 | 3.8 / 8.37 | |
| Electrical requirements (230V, 50/60Hz) | 3.0 A | 4.0 A | ||
| Cat. No. | AAH35045K | AAH35075K | AAH35085K | |
| Electrical requirements (120V, 60Hz) | 5.0 A | 6.7 A | ||
| Cat. No. | AAH35043U | AAH35073U | AAH35083U | |
? Permissible environmental conditions: temperature (5 - 40?) and relative humidity (up to 80%).
? CSA except for T-18Q. ? RoHS for T-14S.
Manufacturer Part Number/SKU: AAH35083U-EA
